Technical Data
- System 100-120 / 220-240 / 380-440V AC -25%+20%, 48-63 Hz
- Auxiliary Built In (from 3 Phase)
Supply Voltage
- Output Contacts2 CO
Output Contacts
- Phase SequenceYes
- Phase Unbalance4 % - 20 % [Variable]
Trip Setting(Volts)
- Under Voltage380-440V AC
220-240V AC
100-120V AC285-425V AC
165-225V AC
75-115V AC - Over Voltage380-440V AC
220-240V AC
100-120V AC400-520V AC
230-290V AC
105-145V AC
- Phase FailureInstant
- UV/OV 1 to 10 Sec [Variable]
Trip Time Delay
- Resetting Mode Auto/ Manual Reset [Selectable]
Resetting Mode
- Weight110 gms.(Approx)
Weight
- Overall (L x W x D)90 X 35 X 60
- Mounting (L x W)35 mm Rail Mounting
Dimensions (mm)
- Wherever not specified Contact Rating : 5A @ 230 V AC (resistive)
